20-Gallon Two Stage Gasoline – AM2-SH09-20M

AM2-SH09-20M

This model features a powerful and efficient two stage compressor designed to maximize productivity. The versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models.

Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator

Frame: Powder coated ASME coded 20-gallon receiver tank · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 16 1/2-inch fly wheel · Quality pilot valve unloader

*Equipped with 150-PSI maximum rated regulator

Specifications

CFM @ 175 PSI*

17.2

Displacement/ Engine

270cc Honda GX270 OHV

Compressor

Two Stage, Cast Iron

Tank Size

20 gallon

Engine Idle Control

Pneumatic

Weights & Dimensions

Net Weight

306.00 lbs.

Shipping Weight

356.00 lbs.

Length

37.00 in.

Width

18.00 in.

Height

38.00 in.

Options

AX-0003 Manual Drain/Regulator/Metal Bowl

Drains moisture from air system

AX-0015 Electric Start – Battery and Cables Not Included

For easy starting

IX-0055 Remote Start/Choke

Remote start/choke; 6-foot wire extension for key switch; you will also need to order electric start option, AX-0015

IX-0059 Remote Start/Choke

Remote start/choke; 6-foot wire extension for key switch, sealed cable; you will also need to order electric start option, AX-0015

AX-0017 Electric Start – Sealed Battery and Cables Included

For easy starting

Limited Warranties:

2 Year Pump Exchange

3 Year Honda Engine
