8-Gallon Single Stage Electric – AM1-PE15-08M

AM1-PE15-08M

The popular 8-gallon electric air compressor features advanced technology and performance so you can power up everything from drills to grinders and paint guns. Its portability makes it a great choice on many jobsites.

Compressor Pump: Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator

Motor: Auto start/stop – continuous run optional · Thermal overload motor protection

Frame: Powder coated 8-gallon twin tank receivers · 3/16-inch base plate to reduce vibration · 16-gauge powder coated two-piece belt guard · 10-inch flat-free tire

Components: Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · Industrial grade pressure switch · 10-inch fly wheel · Start/stop control set at 95 to 125-PSI (Not on continous run models)

Specifications

CFM @ 90 PSI

7.3

Horsepower/Motor

1.5 HP, 120V, 13.2A

Compressor

Single Stage, Cast Iron

Tank Size

8 gallon

Plug Type

NEMA 5-15P

Weights & Dimensions

Net Weight

170.00 lbs.

Shipping Weight

190.00 lbs.

Length

44.50 in.

Width

18.50 in.

Height

25.00 in.

Options

AX-0002 Auto Drain/Regulator/Plastic Bowl

Drains moisture from air system

AX-0003 Manual Drain/Regulator/Metal Bowl

Drains moisture from air system

AX-0078 Stationary Option

Converts the portable model to a stationary model, removes the wheel

AX-0005 Dual Control

Compressor can be operated in start/stop mode or continuous run where pilot valve exhausts air to atmosphere

Limited Warranties:

1 Year Electric Motor

2 Year Pump Exchange
