High volume, zero waste – No more wasted time on calibration or trial and error. You’ll always print on the very first label
40-second changeovers – Change materials in just 40 seconds with faster ribbon removal and intuitive loading.
More intuitive. Less intimidating – The 7″ touchscreen guides you through the printing process, eliminating confusion and the need to grab an expert.
3″ core – revolutionized – Smart technology and automated features equipped for 3″ core printing.
Endless label printing possibilities
The i7500 prints labels for too many applications to list – here are just a few to highlight:
DataCom | Wire ID | Product ID | Electronics
Label printing completely reimagined
Easily manage high-volume, high-mix printing with intuitive features that get you to the finish line faster.
1-button ribbon removal: Collapsible spindle for faster, safer, cleaner removal of spent ribbon with no cardboard core required
Smart ribbon & media rolls: Printer detects and auto-centers the i75 Series ribbons so ink is always facing the right way; and all i75 Series rolls are automatically adjusted for speed, size, heat, layout and approved ribbon/material pairings
Auto-centering media flanges: Automatically centers 3″ core media rolls for precise center-justified printing
40-second changeovers: i75 Series labels and ribbons auto center with no sensor adjustments, calibration or wasted labels
Auto-lifting head: Printhead automatically lifts after printing to eliminate pressure indentations and residual ribbon transfer lines
Easy-access feed path: Wide opening optimizes light and line of sight to the print path sensor and guides when side-loading media
Motorized label optical sensor: Auto-detects installed material and sets sensor to correct mode and moves it to correct location
Field-replaceable printhead with interchangeable dpi: Tool-less, user-replaceable printhead using a single-release pin and connectors
Specifications
Dimensions
Internal Rewind Takeup Core Size: 1.5″
Dimensions: 14.6″(H) x 11.5″(W) x 20.9″(D)
Core Diameter: 3″
Display Size: 7″
Product Features
177226
177714
177717
Cut Options Available
Auto Cutter accessory available, Perforation Cutter accessory available
Cut at the end of print jobs, Cut between label rows, Cut between label sets, Tear
Cut at the end of print jobs, Cut between label rows, Cut between label sets, Tear
Cutter Type
None
Auto Cutter (cut off)
Auto Cutter (cut off)
Attachment Type
None
Auto Cutter
Auto Cutter
Color: Blue, Gray
Application: Asset Tracking, Barcode Labeling, Circuit Board Labeling, Data and Telecommunications Labeling, Electrical Labeling, General Identification, Inventory and Inspection Labeling, Laboratory Labeling, Solar Panel Labeling, Tamper Indicating Labels, Warehouse Marking, Wire and Cable Labeling
Device Connectivity: Mobile device connected, PC connected & Stand-alone
Display Type: Color LCD Touch Screen
Estimated Media Changeover Time: 40 seconds
Keyboard Type: None
Media Sensor Type: Black Mark, Continuous, Gap Sensor, Notch
Memory: 512 MB RAM, 195 MB IFFS Flash
On Screen Indicators: Bluetooth Status, Data Reception, Digital Clock, Error Messaging, Ethernet Status, i75 Smart material / Manual Material, Label dimensions, Print Job Preview, Ready State, Ribbon and label part number recognition, Supply Remaining, USB Connection, User-defined Printer Name, WiFi
Plug Type: US
Power Supply Voltage: 100 – 240 V @ 50 – 60 Hz
Auto Shut-Off / Power Conserve: Yes
Print Preview Feature?: Yes
Units: Inches, Millimeter, Points
User Interface Type: Touchscreen and PC
Battery Type: Internal, not removable
Operating System: Windows® 10, Windows® 11, Windows® 8.1, Windows® Server 2012, Windows® Server 2012 R2, Windows® Server 2016
Printing Specifications
Automatic Label Set Up: Yes
Barcode Symbologies – 2D: Aztec, Data Matrix, GS1 DataMatrix, MaxiCode, MicroPDF417, PDF417, QR code
