California Air Tools 4.0 HP, 20 Gal. Ultra Quiet Air Compressor

California Air Tools 20040CAD Ultra Quiet Air Compressor

Manufacturer: California Air Tools

Part Number: CAT-20040CAD

Description: The CALIFORNIA AIR TOOLS 20040CAD Ultra Quiet & Oil-Free Air Compressor is designed to be one of the quietest air compressors in the industry having only 75 decibels of sound.

4.0 HP (Rated/Running)

20.0 Gallon Steel Tank

12.8 CFM at 40 PSI

10.6 CFM at 90 PSI

The Powerful Twin 2.0 HP (SP-9421-22060) motors operate at only 1680 RPM creating less noise and less wear.

The SP Series of Ultra Quiet Air Compressor Motors have been designed to increase duty cycle and allow for longer continuous run times (i.e. may run continuously at 5.3 cfm @90 PSI, or up to 30-40 minutes at a time, at 10.6 cfm @90 PSI).

The Oil-Free Dual Piston Pump System is engineered for high performance and durability.

The CAT-20040CAD Air Compressor has a Oil-Free Dual Piston pump designed to have a life cycle before wear of 3000 Plus hours compared to other comparable air compressors with life cycles of 1500 hours or less.

The Oil-Free pump allows for use in a variety of temperatures (cold starts) and uneven terrains (no oil in the pump).

The large 20 Gallon Steel Air Tank is just the right size for shop or garage.

EZ-1-2321 Auto Drain Valve Factory Installed

The California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank.

The manually set timer allows you to set the time for both the frequency and duration of the draining process. (Factory Pre-Set)

Designed for the person looking for Power, Air Flow and Less Service with at Least 30% Less Noise!

Features:

Ultra Quiet – Only 75 decibels

Oil-Free Pump – Cleaner air for better tool operation. Less maintenance and Costs.

Two pressure control gauges

One – Female Industrial “Push to Connect” quick connector

Condor Pressure Switch

Thermal Overload Protector

125 PSI Maximum Pressure

220 Volt / 60 Hertz / Single Phase (No 208 Volts – if necessary, obtain 208 to 220 voltage booster)

Low Amp Draw – 14 Amps

Time to fill tank from empty to full – 150 Seconds

Recovery time from 95 PSI to 125 PSI – 40 Seconds

Duty Cycle – 70/30

Maximum continuous running 30-60 min. (Depending PSI & CFM)

Less heat which dissipates more efficiently

20 Gal. Steel AirTank – pounds and easy to move around.

EZ-1-2301 Auto Drain Valve Factoy Installed

The California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank.

L (39″) x W (15″) x H (28″)

148 lbs

1 Year Limited Warranty

Comes complete (4) Air Filters

Plug Type: Nema 6-15P (fits Nema 6-15R or 6-20R receptacle)

Commercial Use: Refer to State & City Codes

Non-ASME Air Tank

Assembled in USA with Global Components
