The HCT2-200-11 Hot Air Pencil is the latest addition to Metcal’s convection rework tools. This digital handheld convection tool is ideally suited for light rework applications, which use smaller components and integrated circuits.
As component miniaturization continues (i.e. 01005 components) the ergonomics of a pencil allow a user more freedom to access and rework components on the board without affecting adjacent parts. Larger handheld convection systems commonly reflow and dislodge adjacent components due to a higher minimum airflow.
The HCT2 series of Digital Hot Air Pencils have always included an array of nozzle sizes and precision control. The HCT2-200’simproved thermal performance allows the user to target a larger variety of components. Metcal has made working under a microscope easier with the optional bent nozzles. Add the HCT2-200-11 to your workbench and experience improved performance.
HCT2-200-11 was developed for very small surface mount component and package sizes (1206’s and smaller) and low board densities. For denser PCBA’s or applications with heavy copper planes; boards> 4 layers; or components larger than 5mm, use of a Metcal preheater (PCT-100 series) maybe necessary.
Specifications
Input Voltage: 110 VAC, 60 Hz
Rated Power: 200 W
Source Temperature: 100 – 450°C (212 – 932°F)
Heating Method: Convection
Airflow: 1.5 – 7 l/min
Noise Level: < 52 dBA at maximum airflow
Surface Resistivity: 105 – 109 Ohm
Display: Temperature & Air Flow
Size W x D x H: 10.6 x 21.3 x 17 cm (4.2″ x 8.4″ x 6.7″)
