GRACO 26C962 – XTR5+ Gun, Hose & Tip Kit, 7250 PSI

GRACO 26C962 – XTR5+ Gun, Hose & Tip Kit, 7250 PSI

XTR5OL Kit with XHD417 SwitchTip designed for heavy-duty protective coating applications. Features the XHF High-Flo gun system optimized for heaviest coatings and fibrous materials with oversized fluid passages and filterless design for maximum flow and superior atomization.

Features:

Bundle, replace and save with this Graco XTR5+ Gun, Hose and Tip Kit. The new self-locking needle assembly of the XTR5+ breaks down for cleaning or rebuilds without the need for cumbersome tools. The appearance of the XTR5+ reflects the Xtreme Duty Hose included, providing confidence that hose to tip are rated to 7250 PSI maximum working pressure. Combine all of this with multiple Graco XHD RAC tips and you’re ready to spray the most challenging of materials.

Protective coatings solution in a box – saving you time and money.

Save time and money replacing your wetted components

Faster gun rebuilds with self-locking needle design

XTR5+ maximum fluid pressure: 5000 PSI (345 bar, 34.5 MPa)

Xtreme Duty Hoses included: 3/8 in x 50 ft (15 m), 1/4 in x 6 ft (1.8 m)

Multiple XHD RAC tips included – (2) XHD519

Additional Specifications

Max Working Pressure: 7250 PSI (500 BAR)

Tip Type: XHD417 SwitchTip

Hose Type: Xtreme Duty 3/8 in. x 50 ft (15 m) Hose and 1/4 in. x 6ft (2 m) Whip Hose

Includes	XTR5+, 3/8 in x 50 ft (15 m) Xtreme-duty Hose, Reducing Nipple, 1/4 in x 6 ft (1.8 m) Xtreme-duty Hose, (2) XHD519 RAC SwitchTip
Maximum Working Pressure (MPa)	34.5
Maximum Working Pressure (psi)	5000
Number of Pieces	6
Type	Spray Gun Kit

Features

Oversized fluid path for minimal flow restriction and maximum flow

Filterless design to minimize pressure drop for superior atomization

Factory-set needle with no adjustment required

Heavy-duty design for maximum performance and long life

Form-fitting handle for maximum control and comfort

Quick disconnect and lightweight design

Applications

Heavy protective coatings

Fibrous materials

High-viscosity coatings

Heavy-duty spray applications

Compatible Equipment

XHF Airless Spray Gun 7250 PSI (500 BAR)

Related Parts

26C963 – XTR7+ Gun, Hose & Tip Kit, 7250 PSI

273142 – XTR5+ Gun, Hose & Tip Kit, 7250 PSI (500 Bar)

273143 – XTR7+ Gun, Hose & Tip Kit

26C972 – XTR5+ Gun, Hose and Tip Kit, 8-pack of 26C962 with Display Stand

26C973 – XTR7+ Gun, Hose and Tip Kit, 8-pack of 26C963 with Display Stand

Kit Contents

XTR5OL gun

XHD417SwitchTip

XTR520 – gun

XHD519 – tips (2)

Xtreme Duty 3/8 in. x 50 ft (15 m) Hose

1/4 in. x 6ft (2 m) Whip Hose

Part of the XHF High-Flo gun system designed for the heaviest coating applications Part of XTR+ Gun and Hose Kit series. Also available in 8 pack with display as part number 26C972.

Reference Manuals

3J0416ENAP-A (Page 12)

3J0679EN (Page 12) ENEU

3J0679ENEU (Page 12)

null (Page 2)

3A7469 (Page 21) XTR5+ and XTR7+ Airless Spray Gun
