SATA Air Vision 5000

Manufacturer: SATA

Part Number: 1000XXX

Description: The SATA air vision 5000 offers complete head and breathing air protection against solvent vapor and isocyanates, puts the focus on effective health protection and lets you experience a whole new and comfortable way of breathing, due to a completely re-designed breathing air supply system. SATA air regulator belt with SATA air regulator (no charcoal) to be used in combination with wall-mounted three-stage filter regulator units, e.g. SATA filter 484 or 284. It’s very comfortable to wear and has a tip-up visor. Supplied air respirator hood with very high wearing comfort and optimum hygiene. The system perfectly complies with painters’ requirements and protects their respiratory tracts, eyes, skin and hair (especially important for the application of waterborne paints). High breathing air quality due to an air supply which is independent from the ambient air, no inhalation resistance, high breathing comfort.

Technical Data

Required Operating Pressure:	25–125 PSI
Required Minimum Air Flow:	6 CFM
Maximum Air Flow Volume:	15 CFM

Product Benefits:

NIOSH approved High breathing air quality


Rigid bump cap for safer work conditions


To be used in combination with wall-mounted three-stage filter regulator units


Absolute safety through external supply of clean air to the cabin—up to 100 times TRK value and suitable for continuous use


No inhalation resistance, very comfortable breathing


Ergonomic design with individual adjustment options and one-hand operation of the visor


Little operating costs, quick pay-off of purchase costs


Soft-stream flow-optimized air distribution in the hood


Reduced sound level: 64 dB (like a conversation at 1m)


The SATA color code discs allow you to personalize the hood, SATA air regulator and SATA air carbon regulator

Versions Available:

SATA air vision 5000 regulator set Includes SATA air vision 5000 hood, SATA air regulator belt, SATA air regulator (no charcoal) Order No. 1005603
SATA air vision 5000 carbon regulator set Includes SATA air vision 5000 hood, SATA air regulator belt, SATA air carbon regulator. Version with activated charcoal adsorber Order No. 214718
SATA air regulator belt set Includes SATA air regulator belt, SATA air regulator (no charcoal) Order No. 1000116
SATA air carbon regulator belt set Includes SATA air regulator belt, SATA air carbon regulator Order No. 1000075
SATA air regulator only Can be swiveled and adjusted on belt unity by up to +/-45°. To be used with three stage filter unit Order No. 1000207
SATA air carbon regulator only Can be swiveled and adjusted on belt unit by up to +/-45°. To be used with two stage filter unit Order No. 1000182
SATA air regulator belt Comfortably cushioned belt allowing the individual adaptation and upgrade for modules Order No. 1000223
SATA air vision 5000 hood only with pressure gauge The ergonomic design with a host of options for individual adaptations and soft-stream flow. Optimized air stream provides highest wearer comfort Order No. 1005596

Additional Accessories (Purchased Separately)

Activated Charcoal Filter for SATA Air Carbon Regulator Order No.
SATA Filter 500 Series Triple-stage sinter filter, fine filter, activated carbon filter, with pressure regulator and outlet module. Order No.
SATA air vision 5000 air warmer for air carbon regulator Order No.
SATA air vision 5000 air warmer with adapter plate & hip pad Order No.
SATA air vision 5000 air cooler with adapter plate & hip pad Order No.
X767 Guardian Carbon Monoxide Monitor These monitors provide continuous LCD digital readout of CO levels from 0 to 199 ppm and operate with the reliable electrochemical sensor Order No.
X288 Sentinel CO Monitor Affordable, easy to use, perfect for smaller sized shops. Attaches to the wall. LCD readout. Continuously samples compressed air for carbon monoxide to comply with OSHA rules. Both audible and visual alarms at 10ppm CO. Order No.
SATA air vision 5000 Silicone Free Breathing Air Hose Order No.

Spare Parts:

G1/4f GS Respirator, UBE + Blow-Off Gun, Size 14

Humidifier Module Cartridge Only

206961 Inner Shell*

Head Fixation Coupling

Belt With Buckle

Hip Pad, One

Adapter Plate

Visor Foil, 6 Perforations (5 Pcs)

Visor Foil, 6 Perforations (20 Pcs)

Visor Foil, 6 Perforations (1000 Pcs)

Hose Clamp

211904 CCS Disc (4 Pcs)*

Hygiene Insert (20 Pcs)

Comfort Band, Velcro Attachment (10 Pcs)

Visor Bolt (6 Pcs)

Hook-And-Loop Tape, Long (1 Pc), Short (1 Pc), Adhesive On One Side

Hood Holder For SATA Air Regulator

Visor Foil, 6 Perforations (50 Pcs)

Visor Foil, 6 Perforations (100 Pcs)

Safety Quick Coupling For SATA Air Regulator & SATA Air Carbon Regulator, Air Warmer, Cooler, Humidifier

Air Carbon Regulator Cap

218206-1 O-Ring*

SATA Activated Charcoal Filter, Complete

Plug-In Diffuser

Humidifier Kit Consisting Of Humidifier Module, Lid Seal & SATA Filter Timer

Dark Grey Hood Cloth

SATA Air Regulator Belt (NIOSH)

SATA Air Regulator Belt (Plus Size)

Pressure Gauge

Complete Air Hose


Velcro Comfort Head Band (100 Pcs)

Control Knob Cpl

1076521 Machine Screws For Humidifier*

Air Tube For SATA Air Humidifier

1076612 Container For SATA Air Humidifier*

Lid For SATA Air Humidifier

1076638 Safety Band For Bayonet Coupling, SATA Air Humidifier*

1076662 Pressure Relief Valve Cpl For SATA Air Humidifier*

1076688 Angled Screw Coupling, Swiveling For SATA Air Humidifier*

1076703 Safety Quick Coupling*

Literature:
