SATAjet 1000 K RP DA Spray Gun

SATAjet 1000 K RP DA

Manufacturer: SATA
Part Number: 211979, 1004928

Description: SATAjet 1000 K RP D—The SATAjet 1000 K is the small, lightweight and fast pressure fed spray gun for craft and industry, available in a special version for the application of glues/adhesives with a round fan. This nozzle set has a size of 1.6. Available with or without fan control.

Total Finishing Supplies is an authorized SATA Distributor. Beware of sites that claim to offer genuine SATA items. They may not be authorized and you may be buying a fake or an item that won’t be covered under SATA’s warranty.

SATAjet 1000 K DA Product Benefits:

Suitable for the application of various materials—waterborne or solvent-based

Special air passages on the air cap horns prevent material accumulations caused by overspray

Universally adjustable spray pattern with fine atomization for a high work speed

The wide and smooth material passages improve the material flow – reduces cleaning time and ensures perfect paint jobs

Extensions available in various configurations

SATAjet 1000 K DA-R Product Benefits:

Suitable for the application of glue

Round spray only

Fluid and fan lock-out

Technical Data

Max. Inlet Air Pressure:

Air Consumption:

Spray Distance:

Material Connection:

29 PSI

9.7 CFM @ 29 PSI

7 in.– 9in.

G 3/8” Male Thread

Nozzle Sets

211961 1.3

1004944 1.3 DA-R

Required Accessories For SATA Pressure Fed Spray Guns

SATA Paint Tube G 3/8” (Female Thread)–3/8” (Male Thread) For SATA Pressure Fed Spray Guns

SATA Paint Strainer 60 Mesh, G 3/8” (Female Thread) & 3/8” (Male Thread) For SATA Pressure Fed Spray Guns

Accessory & Part List

Air Piston Seal

Universal Wrench

Type 1 Wand Coupling


Trigger Pin Circlip

Large Nozzle Brush

Air Micrometer Pin

Lower Trigger Pin

Color Code Clips (4 Pk)

4mm Allen Key

Upper Trigger Pin

Paint Needle Bushing

14993* Needle Bushing Spring

Needle Packing Kit

Tension Spring Washer

17897* Needle Spring

Needle Seal

Type 1 Round Spray Nozzle


End Cap O-Ring


3/8″ To 1/4″ Paint Pipe


2mm Allen Wrench

End Plug


Air Piston

Tool Set

93526* Material Connection

Air Cap Ring Seal

Air Cap Ring Only (RP)

130484* Insert With Needle Packing Kit

Trigger Kit

Air Distribution Ring (3 pk)

130534-1* Air Distribution Ring

SATAjet 1000 K Repair Kit

Trigger Sleeve Kit

Air Piston Bushing

Spring Kit, 3 each of #215806 & #17897

Air Micrometer Pin (3 pk)

¼” Male Thread Air Inlet Fitting

Air Piston Seal (3 pk)

Fluid Control & Lock Nut Kit

Fluid Tip Seal (5 pk)

Air Distribution Ring (3 pk)

Mixing Nozzle


Air Piston Spring

Repair Kit—

Air Piston Service Unit

Sealing Kit

Tool Kit—

Extraction Tool

Paint Strainer

Cleaning Brush

2mm Allen Wrench

4mm Allen Wrench

Universal Spanner Wrench

Universal Key Kit
