View Solutions SZ19040231 ESD-Safe Trinocular Microscope with Gliding Post Stand

Specifications

Optical System

System Optical Magnification: 7-50X

System Field of View: Dia. 4-28.57mm

System Working Distance: 103mm

Trinocular Zoom Body

Body Magnification: 7.0-50x

Zoom Range: 0.7-5.0x

Zoom Operating Mode: With Two Horizontal Knobs

Nosepiece Adapter Size for Ring Light: Dia. 54mm

Eye Tube Adjustment Mode: Siedentopf

Erect/Inverted Image: Erect image

Eye Tube Rotatable: 360° Rotatable

Interpupillary Adjustment: 45-65mm

Eye Tube Inner Diameter: Dia. 30mm

Eye Tube Diopter Adjustable: ±5°

Eyepiece Type: Standard Eyepiece

Eyepiece Optical Magnification: 10x

Plan Eyepiece

Eyepiece Size for Eye Tube: Dia. 30mm

Eyepoint Type: High Eyepoint Eyepiece

Eyepiece Size for Reticle: Dia. 24mm

Eye Guard Installation: Independent Eye Guard

Eye Guard Mount Size: Dia. 36mm

Built-in Objective Magnification: 1.0x

Objective Working Distance: 103mm

Objective Screw Thread: M48x0.75mm

Surface Treatment: Spray Paint

Material: Metal

Color: Orange

Net Weight: 1.27kg (2.80lbs)

Post Stand

Vertical Post Height: 225mm

Vertical Post Diameter: Dia. 32mm

Base Type: Table Base

Base Shape: Rectangle

Base Dimensions: 125x275x55mm

Focusing Distance on Horizontal Direction: 190mm

Focus Mode: Manual

Surface Treatment: Natural Oxidation

Material: Metal

Color: Silver

Net Weight: 6.50kg (14.33lbs)

Dimensions: 125x275x280mm (4.921×10.827×11.024in.)

Focus Rack

Holder Adapter Type: Dia. 76mm Scope Holder

Focus Mode: Manual

Focus Distance: 50mm

Coarse Focus Distance per Rotation: 22mm

Post Hole Diameter of Focusing Rack: Dia. 32mm

Center Distance from Hole to Scope Holder: 155mm

Surface Treatment: Spray Paint

Material: Metal

Color: Black

Net Weight: 1.00kg (2.205lbs)

Coupler/C-mount Adapter

Coupler Mount Type for Trinocular: Fastening Screw

Coupler Mount Size for Trinocular: Dia. 38mm

Adjustable Coupler: Adjustable

Coupler for Microscope Type: Stereo Compatible

Coupler Magnification: 0.5X

C/CS-Mount Coupler: C-Mount

Surface Treatment: Electroplating Black

Material: Metal

Color: Black

Net Weight: 0.10kg (0.22lbs)

Other Parameters

Surface Treatment: Spray Paint

Material: Metal

Color: Black

Net Weight: 8.85kg (19.51lbs)

Dimensions: 125x275x280mm (4.921×10.827×11.024 in.)

Product Overview

More Information

SKU	I202478
Part No.	SZ19040231
Brand	View Solutions
ESD-Safe	Yes
Magnification	7.0x-50x
Mount	Post Stand
