ZIP 52 Finishing Low-Pressure Double Diaphragm Pumps
Manufacturer: Wager Part Number: U76x.00
Description: ZIP 52 Finishing pack with FFC (Fine Flow Controller), air regulator, fluid regulator and suction hose
NOT INCLUDED: Fluid/Air Hose set, linked below
The ZIP 52 pneumatic double diaphragm pumps are designed with a reduction in air consumption coupled with better performance and maximum reliability. The exclusive design enables its use for corrosive, abrasive, and highly viscous liquid media. ZIP pumps cover a broad application spectrum, including the feeding of paint supply systems; the feeding and circulation of printing ink, solvents, paints, chemicals, and oils; the disposal of liquid waste; the supply of flow viscosity adhesives; and filling/emptying of tanks, drums, and containers. These pumps are offered in aluminum and stainless steel with a volumetric flow of 13.7 gal/min and 1/2” material inlet/outlet size for an extended range of materials.
The ZIP Finishing advantage
The Wagner ZIP 52 Finishing meets the highest expectations in surface coating quality. The Fine Flow Controller (FFC) with the integrated material filter guarantees the smoothest material transportation
Special long-life diaphragms enable the pump to run at high speeds and attain high-performance standards for long periods of time without damage
Designed for versatility in application
The ZIP 52 double diaphragm pumps are available in stainless steel and aluminum models to fit any type of application needs for material supply
High efficiency and performance
The optimized design with less dead space enables rapid color change and cleaning, and a reduction in the amount of solvent required
The air motor ensures the highest performance with reduced air consumption; requires no additional lubrication and suffers from no freezing problems
Different pump configurations and a comprehensive product palette guarantee a wide range of possible applications
Specifications: Pump Ratio: 1:1 Volumetric Flow: 13.7 gal/min 1.8 CFM Inlet and Outlet: BSP 1/2” Material Pressure: 116 PSI (7.8 bar) Sound level at max. flow rate and a feed pressure of 116 PSI: 85 dB (A)
